Hybrid Analog/Digital Single Phase/Three Phase sensing 8 Amp AVR for self-excited (shunt), Auxiliary and PMG brushless generators
The ADVR-083 is equipped with Under Frequency and Over Excitation protection, along with an output voltage Soft Start function. It also features Quadrature Droop Input for use in generator paralleling. Employing a digital circuit for voltage sensing and under frequency protection, it can effectively minimize the output voltage variations and under frequency knee point drifted affected by the changes of environment temperature.
Features
- Voltage Sensing Input and Power Input can be single-phase or 3-phase
- Over Excitation Protection // Under Frequency Protection // Soft Start voltage ramping
- Can be used with generators operating parallel
- Built-in high capacity protection fuse
- Built-in EMI suppression
- Can be used together with KUTAI Auxiliary Excitation Booster to increase motor starting capability of self-excited (shunt) generators
- Digital circuit for voltage sensing and under frequency protection
- Effectively minimize the output voltage variations and under frequency knee point drifted affected by temperature changes
Specifications
