EA75A220HL / EA75A220FL

Product Inquiry

Carbon Brush Gensets AVR 75Amp

The EA75A220 series Automatic Voltage Regulator is specifically designed for self-excited brush-type generators, offering Full Wave (EA75A220FL) and Half Wave (EA75A220HL) version. It features built-in low frequency protection and forced-air cooling fan. Optional models for generator parallel operation are available, providing flexible options to meet various application requirements.
Features
  • Voltage regulation less than +/-1%
  • 50/60 Hz selectable
  • Full wave and half wave version available
  • Adjustable voltage, stability and field limit
  • Built-in high breaking capacity fuse
  • Forced-Air Cooling by internal fan
  • Under frequency protection
Specifications
