Rated Voltage 100 to 600 Vac
Rated Current 1600Amp
ATS3BC1600 (3 Poles) / ATS4BC1600 (4 Poles)
The Standard ATS package includes ATS Intelligent Controller *, PTM-100/PTM-400 (Voltage Transformer Module), BTS (Basic Transfer Switch), all the connection harness and indoor enclosure (outdoor type is optional).
* Select ATS-245/ATS-385/ATS-465 based on the system voltage.
* Select ATS-245/ATS-385/ATS-465 based on the system voltage.
Features
- Extraordinary modularized ATS design *1
- Superior serviceability & simple maintenance
- ATS-245/ATS-385/ATS-465 Intelligent Controller：Voltage monitoring & protection with built-in 1 to 4 weeks exerciser timer
- PTM-100/PTM-400Voltage Transformer Module：Change voltage easily by using pin terminal
- BTS：Transfer switch built with high short circuit breaking capacity & OCPD *2
- All modules connected by harness with high voltage withstand plug-in connectors sets
- Complies with IEC60947-6-1 requirements *3
Specifications
