Residential Automatic Transfer Switch 4P 125Amp

TCS4P125 are brand new modularized design Automatic Transfer Switch (ATS). With rated current of 125A and rated voltage of 110 Vac or 220 Vac single phase, 3 phase or 3 phase 4 Wire to choose from. It is electrically and manually operated. This Automatic Transfer Switch is ideal for household and telecommunication cell site use. All plastic parts used on the ATS are made with UL 94V-0 plastic to comply with the highest safety standards. It provides genset remote start signal and programmable weekly engine exercise timer with options from one to four weeks with load or without load to ensure the stability of power supply.
U.S. Pat. No. US 9,257,871 B1
TAIWAN Pat. No. M491940
CHINA Pat.No.ZL 2014 2 0473370.2
  • Modular design for installation next to switch or on the door
  • Electrically or manually operated, mechanically held contacts
  • Adjustable time delay in neutral position
  • Compact size with user-friendly status LED display
  • Monitor Normal & Standby source OV and UV
  • Built-in 1 to 4 weeks with / without load exerciser
  • Made with UL 94V-0 plastic
  • Designed for telecom industry or home ATS applications
