ADVR-054

Product Inquiry

Self Excited 5Amp Automatic Voltage Regulator with High Cooling Efficiency

ADVR-054 has large heat sink which significantly increases cooling efficiency. This AVR has over excitation protection and it can automatically shut-off output when voltage sensing is lost. Employing a digital circuit for voltage sensing and under frequency protection, it can effectively minimize the output voltage variations and under frequency knee point drifted affected by the changes of environment temperature. Compatible replacement for Basler KR7, Airman DST-100-2, Markon 36245, Markon MD1C, Sincro BL4,Datakom AVR-4.
Features
  • Compact size, robust and high reliability
  • Innovative heat sink significantly increases cooling efficiency
  • 220/380/440/480 Vac selectable input
  • Soft start voltage ramping
  • Over excitation protection
  • EMI suppression
  • Automatic shut off output when voltage sensing is lost
  • Built-in high capacity fuse
  • Use with KUTAI EP200 Paralleling Module for parallel operation
  • Digital circuit for voltage sensing and under frequency protection
  • Effectively minimize the output voltage variations and under frequency knee point drifted affected by temperature changes
Specifications
