Paralleling Module

EP200 Universal Droop Module (Reactive factor compose module) for paralleling KUTAI generator voltage regulator EA04A, EA04C, ADVR-054, EA460, EA63-2.5 and EA63-2.5S.
Features
  • Single phase reactive factor compose 50/60 Hz
  • Low power dissipation Max. 1 VA
  • Current Transformer (C.T.) input N:5A or N:1A.
  • Together with external, parallel current transformer provides droop signal
  • Works with different models of Kutai AVR
Specifications
